5.14.2.2.2 The I/O Bindings . Output Parameters
NOTE: The default value for all the Output entities are None.
5.14.2.2.2.1 Solenoid Control
If a running batch contains additives, the particular additive solenoid
must be opened and closed when an additive injection is triggered
(solenoid open/close is signalled).
5.14.2.2.2.2 Block Valve Control
If the [Block valve] I/O binding is defined, then the block valve output
must be active when the permissive is <True>.
The block valve must remain active until the stream permissive is
<False>.
5.14.2.2.2.3 Injection Feedback
This functionality is enabled by defining the additive injector
feedback I/O binding.
Some injector-feedback modes produce pulses of a fixed length. For
these modes, the length of the pulse is determined by the feedback
pulse duration entity. The modes in which this setting is applicable
are marked as underscored italic
.
The specific behavior of the additive injector feedback is defined by
the entities located in the Solenoid submenu.
Piston Switch - The injector feedback output is active as long as
the additive injection solenoid is active.
Inverted piston switch - The injector output is inactive as long as
the additive injector solenoid is active (inverse of previous mode).
Post injection
- A pulse is generated as soon as the additive
injector solenoid becomes inactive.
Entity Description Can be linked to...
[Solenoid control]
With this entity you can select the
physical source for the additive
solenoid control function.
Any of the unused DO-SSR-n, DO-EMR-n,
PO-n, or None.
[Block valve control]
With this entity you can select the
physical source for the block valve
control function.
Any of the unused DO-SSR-n, DO-EMR-n,
PO-n, or None.
[Injection feedback]
With this entity you can select the
physical source for the injection
feedback function.
Any of the unused DO-SSR-n, DO-EMR-n,
PO-n, or None.
[Pump demand]
With this entity you can select the
physical source for the pump demand
function.
Any of the unused DO-SSR-n, DO-EMR-n,
PO-n, or None.
[Factored pulse out]
With this entity you can select the
physical source for the factored pulse
out function.
PO-1, PO-2, PO-3, PO-4, or None
