Honeywell Fusion4 MSC-L User Manual

System Description - Introduction
Fusion4 MSC-L Part No.: 4418309_Rev09
3- 4 Installation & Operation Manual
Honeywell
In side stream blending, the main product does not have its own valve
and meter. The flow rates of both the main and blend products are
therefore a function of both valves.
FIGURE 3-3 Side Stream Blending Piping
3.1.3.4 Sequential Blending
Sequential blending is a process in which multiple products share a
single flow meter and control valve and are loaded one by one in
sequence. Each product has dedicated pump demand and block
valves. The mixing of the products takes place in the receiving
compartment. The amount of each product and order of loading is
defined by the recipe selected for the batch. See chapter 5 "Operation"
for more details.
FIGURE 3-4 Sequential Blending Piping
