Operation - Interfacing With External Additive Controller
Fusion4 MSC-L Part No.: 4418309_Rev09
5 - 86 Installation & Operation Manual
Honeywell
5.11.4.1 Process Data
Process data screen lists all the streams in the transaction. Transaction
volume of each stream is listed here.
Long press OK button shows process screen while loading. The MSC-L
polls the transaction data for MSC-A streams while loading and
updating process details.
The external additive streams are listed along with internal additive
streams in process data.
The additive transaction volume and ppm values can be viewed on
Process data screen. The visible value can have an error of +/- 1 ml as
decimal part of the volume on the external additive controller is not
available to the MSC-L over Comms.
