Honeywell Fusion4 MSC-L User Manual

Operation - Stream Configuration
Part No.: 4418309_Rev09 Fusion4 MSC-L
Honeywell Installation & Operation Manual 5 - 181
5.14.2.3.2 Solenoid
On the Additive Stream Config. - Stream n- Control Settings screen,
select <Solenoid>.
The Additive Stream Config. - Stream n - Solenoid screen is
displayed with the following entities.
[Feedback mode]
With this entity you can select the type
of feedback for each injection.
<None> (default)
<end sensor piston emul.>
<Piston switch>
<inv.end-sensor piston emul.>
<Inverted piston switch>
<mid-stroke piston emul.>
<Post injection>
<Double pulse>
<Last 25%>
<Ext. piston switch>
<Inv. ext. piston switch>
[Feedback pulse duration]
With this entity you can enter the
duration of the feedback pulse in ms.
<0> ms ... <1000> ms
(default =
<500> ms)
[
Pump run timeout] With this entity you can enter the time
in minutes between the last injection
and the additive pump stop.
<1> min ... <255> mins
(default =
<10> mins)
[Block valve location]
With this entity you can configure the
physical position of the block valve
pertaining to the additive meter.
<Upstream from meter> from (default)
<Downstream from meter>
[Factored pulse width]
Entity Description Value range
[Number of retries]
With this entity you can set the number
of retries for opening the solenoid
again, in case additive pulses are not
received.
<0> ... <2>
(default = <2>)
[Close delay]
With this entity you can set the time in
ms. The additive pulses must be
stopped after the solenoid is closed.
<500> ms ... <10000> ms
(default =
<500> ms)
