Honeywell Fusion4 MSC-L User Manual

Operation - Interfacing With External Additive Controller
Part No.: 4418309_Rev09 Fusion4 MSC-L
Honeywell Installation & Operation Manual 5 - 79
5.11.1 Connecting External Additive Controllers
This section provides information about connecting external additive
controllers like the MSC-A.
5.11.1.1 Topology and Wiring
To connect the external additives,
 Loading arms running on Arm board 1 of MSC-L can use COM1 or
COM2 ports. External additive streams 1-12 are on Arm Board 1.
 Loading arms running on Arm board 2 of MSC-L can use COM6 or
COM7 ports. External additive streams 13-24 are on Arm board 2
The communication uses FMC Smith protocol that needs to be
configured on the COM ports of both devices.
FIGURE 5-28 Block Diagram for MSC-L to MSC-A interface communication
Up to 6 Ext. Additive Streams
per arm board
MSC-L
1 x RS-485
COM1 or
COM2
MSC-A
(6 Streams)
Up to 6 Ext. Additive Streams
per arm board
MSC-L
COM1 or
COM2
MSC-A
(12 Streams)
COM6 or
COM7
1 x RS-485
1 x RS-485
ARM
Board 1
ARM
Board 2
