Honeywell Fusion4 MSC-L User Manual

Operation - Stream Configuration
Fusion4 MSC-L Part No.: 4418309_Rev09
5 - 184 Installation & Operation Manual
Honeywell
The Additive Stream Config. . Stream n . No Pump screen is
displayed with the following entities.
5.14.2.4.4 Block Valve Fault
On the Additive Stream Config . Stream n . Alarms screen, select
<Block valve fault>.
The Additive Stream Config. . Stream n . Block Valve Fault screen is
displayed with the following entities.
5.14.2.4.5 Deviation
On the Additive Stream Config . Stream n . Alarms screen, select
<Deviation>.
The Additive Stream Config. . Stream n . Deviation screen is
displayed with the following entities.
Entity Description Value range
[Alarm action]
With this entity you can configure the
alarm behavior, in case this particular
alarm occurs.
<Disabled> (default)
<Display>
<Display shutdown>
<Display pause>
[Pump feedback timeout]
With this entity you can set the time in
seconds in which the additive pump
must provide a feedback to the MSC. If
the feedback from the pump is not
received in
[Pump feedback timeout],
then an alarm occurs depending on the
[Alarm action]
.
<1> s ... <255> s
(default =
<15> s)
Entity Description Value range
[Alarm action]
With this entity you can configure the
alarm behavior, in case this particular
alarm occurs.
<Disabled> (default)
<Display>
<Display shutdown>
<Display pause>
[Feedback timeout]
With this entity you can set the time in
seconds in which the additive pump
must providea feedback to the MSC. If
the feedback from the pump is not
received in
[Feedback timeout], then an
alarm occurs depending on the
[Alarm
action].
<1> s ... <255> s
(default =
<15> s)
Entity Description Value range
[Alarm action]
With this entity you can configure the
alarm behavior, in case this particular
alarm occurs.
<Disabled>
<Display>
(default)
<Display shutdown>
<Display pause>
