Honeywell Fusion4 MSC-L User Manual

Safety - Safety Instructions for the LAD
Fusion4 MSC-L Part No.: 4418309_Rev09
2- 10 Installation & Operation Manual
Honeywell
2.3.1 General
The LAD is a hand-held controller used for interfacing with the MSC-L.
WARNING! Only use the instrument for its intended purpose.
2.3.1.1 EC declaration of conformity (for EU)
Refer to the EC declaration of conformity and ATEX certificate(s),
shipped with the device for EC declarations.
2.3.1.2 Control Drawings for FM & CSA
Refer to the control drawings shipped with the MSC-L for FM and CSA.
2.3.2 Explosion Safety
WARNING! This is an intrinsically safe device and may only be
connected to devices with compatible intrinsically
safe parameters, such as the MSC-L.
Connection of non-intrinsically safe signals inval-
idates the approval. The electrical data of the intrin-
sically safe circuits is to be taken from the certificate.
2.3.3 Commissioning
The LAD and the Fusion4 parent devices must be commissioned using
this controller trained by Honeywell Enraf. The service technician must
have knowledge of the national, local and company requirements for
electrical equipment in hazardous areas.
2.3.4 Operation
After connecting to the MSC-L, the LAD can be used for its intended
purpose.
2.3.5 Maintenance and Troubleshooting
The LAD hardware is non-servicable, in case of damage contact
Honeywell Enraf for replacement.
Approval Certificate no. Type of protection identification
ATEX KEMA 10ATEX0152 II 2 G
Ex ia IIB T4 Gb
T
a
= -20 °C ... +65 °C
(-4 °F ... +149 °F)
IECEx IECEx KEM 10.0070 Zone 1
FM 3041202 Class I, Division 1 group C, D T4
CSA 11.2395571
Class I, Division 1 group C, D T4
Zone 1 Ex ia IIB T4
