Honeywell Fusion4 MSC-L User Manual

Installation - Wiring Termination Guidance
Fusion4 MSC-L Part No.: 4418309_Rev09
4 - 70 Installation & Operation Manual
Honeywell
CN-203
1 DO-EMR-31 A EMR31_no Signal - Output Low frequency
slow switching
AC or DC output
control.
Alarm shutdown
Alarm indication
Pump start
Product block
valve
Deadman callout
Deadman bell
Secondary
interface for:
Actuator output
Additive solenoid
2 DO-EMR-31 B EMR_common Neutral
3 DO-EMR-32 A EMR32_no Signal - Output
4 DO-EMR-32 B EMR_common Neutral
5 DO-EMR-33 A EMR33_no Signal - Output
6 DO-EMR-33 B EMR_common Neutral
7 DO-EMR-34 A EMR34_no Signal - Output
8 DO-EMR-34 B EMR_common Neutral
CN-204
1 DO-EMR-35 A EMR35_no Signal - Output Low frequency
slow switching
AC or DC output
control.
Alarm shutdown
Alarm indication
Pump start
Product block
valve
Deadman callout
Deadman bell
Secondary
interface for:
Actuator output
Additive solenoid
2 DO-EMR-35 B EMR_common Neutral
3 DO-EMR-36 A EMR36_no Signal - Output
4 DO-EMR-36 B EMR_common Neutral
5 DO-EMR-37 A EMR37_no Signal - Output
6 DO-EMR-37 B EMR_common Neutral
7 DO-EMR-38 A EMR38_no Signal - Output
8 DO-EMR-38 B EMR_common Neutral
CN-205
1 DO-EMR-29 A EMR29_no Signal - Output Low frequency
slow switching
AC or DC output
control.
Alarm shutdown
Alarm indication
Pump start
Product block
valve
Deadman callout
Deadman bell
Secondary
interface for:
Actuator output
Additive solenoid
2 DO-EMR-29 B EMR_common Neutral
3 DO-EMR-30 A EMR30_no Signal - Output
4 DO-EMR-30 B EMR_common Neutral
5 DO-EMR-39 A EMR39_no Signal - Output
6 DO-EMR-39 B EMR_common Neutral
7 DO-EMR-40 A EMR40_no Signal - Output
8 DO-EMR-40 B EMR_common Neutral
Terminal I/O
Floor plan
ID
Signal name
Signal
description
Type
Typical
functions
