Honeywell Fusion4 MSC-L User Manual

Installation - Wiring Termination Guidance
Fusion4 MSC-L Part No.: 4418309_Rev09
4 - 54 Installation & Operation Manual
Honeywell
CN-105
1 DO-EMR-9 A EMR9_no Contact for
External
Supply
Low frequency
slow switching
AC or DC output
control.
Alarm shutdown
Alarm indication
Pump start
Product block
valve
Deadman callout
Deadman bell
Secondary
interface for:
Actuator output
Additive solenoid
2 DO-EMR-9 B EMR_common Contact for
External load
switching
3 DO-EMR-10 A EMR10_no Contact for
External
Supply
4 DO-EMR-10 B EMR_common Contact for
External load
switching
5 DO-EMR-19 A EMR19_no Contact for
External
Supply
6 DO-EMR-19 B EMR_common Contact for
External load
switching
7 DO-EMR-20 A EMR20_no Contact for
External
Supply
8 DO-EMR-20 B EMR_common Contact for
External load
switching
CN-106
1 DO-SSR-1 F SSR1_feed Feed High frequency,
fast switching
AC output
control.
Actuator outputs
Additive solenoid
Additive injection
feedback
Alarm shutdown
Alarm indication
Pump start
Product block
valve
Additive blocking
valve
2 DO-SSR-1 O SSR1_sw Signal - Output
3 DO-SSR-1 N N Neutral
4 DO-SSR-1 L L A/C Live
5 DO-SSR-2 F SSR2_feed Feed
6 DO-SSR-2 O SSR2_sw Signal - Output
7 DO-SSR-2 N N Neutral
8 DO-SSR-2 L L A/C Live
CN-107
Terminal I/O
Floor plan
ID
Signal name
Signal
description
Type
Typical
functions
