Honeywell Fusion4 MSC-L User Manual

Installation - Wiring Termination Guidance
Fusion4 MSC-L Part No.: 4418309_Rev09
4 - 60 Installation & Operation Manual
Honeywell
CN-119
1 DI-DC-4 H DC4_hi Signal - Input DC input control Programmable
Inputs
ESD input
2 DI-DC-4 C COMMON Common
3 DI-DC-5 H DC5_hi Signal - Input
4 DI-DC-5 C COMMON Common
5 DI-DC-6 H DC6_hi Signal - Input
6 DI-DC-6 C COMMON Common
CN-120
1 DI-DC-7 H DC7_hi Signal - Input DC input control Programmable
Inputs
ESD input
2 DI-DC-7 C COMMON Common
3 DI-DC-8 H DC8_hi Signal - Input
4 DI-DC-8 C COMMON Common
5 DI-DC-9 H DC9_hi Signal - Input
6 DI-DC-9 C COMMON Common
CN-121
1 DI-DC-10 H DC10_hi Signal - Input DC input control Programmable
Inputs
ESD input
2 DI-DC-10 C COMMON Common
3 DI-DC-11 H DC11_hi Signal - Input
4 DI-DC-11 C COMMON Common
5 DI-DC-12 H DC12_hi Signal - Input
6 DI-DC-12 C COMMON Common
CN-122
1 DI-DC-13 H DC13_hi Signal - Input DC input control Programmable
Inputs
ESD input
2 DI-DC-13 C COMMON Common
3 DI-DC-14 H DC14_hi Signal - Input
4 DI-DC-14 C COMMON Common
5 DI-DC-15 H DC15_hi Signal - Input
6 DI-DC-15 C COMMON Common
Terminal I/O
Floor plan
ID
Signal name
Signal
description
Type
Typical
functions
