Honeywell Fusion4 MSC-L User Manual

Installation - Wiring Termination Guidance
Part No.: 4418309_Rev09 Fusion4 MSC-L
Honeywell Installation & Operation Manual 4 - 63
CN-131
1 AI-4 24 V 24 V Power (active
mode)
Analog input
control
4-20 mA input for
temperature
measurement.
Digital mode for
"digital input".
2 AI-4 C 24 V common Common
(passive
mode)
3 AI-4 A Analog signal Signal - Input
(active +
passive mode)
CN-132
1 AI-5 24 V 24 V Power (active
mode)
Analog input
control
4-20 mA input for
temperature
measurement.
Digital mode for
"digital input".
2 AI-5 C 24 V common Common
(passive
mode)
3 AI-5 A Analog signal Signal - Input
(active +
passive mode)
CN-133
1 AI-6 24 V 24 V Power (active
mode)
Analog input
control
4-20 mA input for
temperature
measurement.
Digital mode for
"digital input".
2 AI-6 C 24 V common Common
(passive
mode)
3 AI-6 A Analog signal Signal - Input
(active +
passive mode)
CN-134
1 AI-7 24 V 24 V Power (active
mode)
Analog input
control
4-20 mA input for
temperature
measurement.
Digital mode for
"digital input".
2 AI-7 C 24 V common Common
(passive
mode)
3 AI-7 A Analog signal Signal - Input
(active +
passive mode)
Terminal I/O
Floor plan
ID
Signal name
Signal
description
Type
Typical
functions
