Operation - Arm Configuration
Part No.: 4418309_Rev09 Fusion4 MSC-L
Honeywell Installation & Operation Manual 5 - 197
[Minimum preset quantity]
With this entity the minimum preset
quantity can be configured.
Presets entered below this value are
not accepted for a valid batch.
default =
<0> L
[Maximum preset quantity]
With this entity the maximum preset
quantity can be configured.
Presets entered above this value are
not accepted for a valid batch.
default =
<30000> L
[Initial flowrate]
With this entity the rate at which the
final product is initially filled into the
container until the delivered volume is
greater than the Initial Volume is
determined.
<1> L/min to <1000000> L/min
(default = <300> L/min)
[Full flowrate]
With this entity the target flow rate of
the final product when it is neither in
Initial or pre-stop states is determined.
<1> L/min to <1000000> L/min
(default = <1800> L/min)
[Pre-stop flowrate]
With this entity the target flow rate of
the final product when the amount of
delivered product is greater than the
following (Batch Preset Volume - Pre-
stop Volume) is determined.
<1> L/min to <1000000> L/min
(default = <300> L/min)
[Low flow rate]
With this entity you can select the low
flow rate for the product to be
delivered.
<1> L/min to <1000000> L/min
(default = <300> L/min)
[High flow rate]
With this entity you can select the high
flow rate for the product to be
delivered.
<1> L/min to <1000000> L/min
(default = <1800> L/min)
[Vapour line open mode]
With this entity you can select block
valve control open mode with main line.
<Direct>
<Before time>
<After time>
<After quantity>
[Vapour line close mode]
With this entity you can select block
valve control close mode with main
line.
<Direct>
<Before time>
<After time>
<After quantity>
[Vapour line open cond. (time)]
With this entity you can configure block
valve control open condition time.
<0 s>
[Vapour line open cond. (qty)]
With this entity you can configure block
valve control open condition quantity.
<0.00%>
[Vapour line close cond. (time)]
With this entity you can configure block
valve control close condition time.
<0 s>
[Vapour line close cond. (qty)]
With this entity you can configure block
valve control close condition quantity.
<0.00%>
[Batch preset evaluation]
With this entity you can enable or
disable batch preset evaluation. When
disabled, batch preset can be set to
any quantity of 1 L.
<Enable> default
<Disable>
