The following table specifies the hardware I/O specifications of the DC
output 1, DC output 2, and DC output 3.
The following table specifies the hardware I/O specifications of the
common DC output.
The CAN-PSF-MSC board contains a 48 pin (DIN41612 F-type) press-
fit connector. The signals are grouped as high voltage AC signals and
low voltage DC signals.
Efficiency - 80 - - %
Insulation voltage AC Input to all
DC outputs
2500 V - - V
AC
Insulation voltage AC Input to PE 2500 V - - V
AC
Leakage current AC Input to PE - - 3.5 mA
DC Output Item Conditions Minimum Typical Maximum Unit
Output 1 DC Voltage
-
4.75 5.0 5.25 V
DC
DC Current
5.0 V
10.0 - - A
DC OVP
-
6.25 - 7.0 V
DC
Over Current Limit
-
12 - 15 A
Output 2 DC Voltage
-
11.5 12.0 12.5 V
DC
DC Current
12.0 V
2.0 - - A
DC OVP
-
14.0 - 15.5 V
DC
Over Current Limit
-
2.2 - 3.0 A
Output 3 DC Voltage
-
23.0 24.0 25.0 V
DC
DC Current
24.0 V
1.0 - - A
DC OVP
-
28 - 31.0 V
DC
Over Current Limit
-
1.1 - 1.5 A
Item Conditions Minimum Typical Maximum Unit
S/C protection
DC outputs (all) Continuous - constant current
(self-recovering)
-
Load Regulation
DC outputs (all)
- - 1 % -
Line Regulation
DC outputs (all)
- - 1 %
-
Ripple and Noise
DC Outputs (all)
- - 100 mV V
P-P
Ripple and Noise
DC Outputs (all)
- - 240 mV V
P-P
Isolation voltage
DC Outputs (all)
Between DC
outputs
500 - - V
DC
Item Conditions Minimum Typical Maximum Unit
