Honeywell Fusion4 MSC-L User Manual

System Description - Output Functions
Fusion4 MSC-L Part No.: 4418309_Rev09
3- 58 Installation & Operation Manual
Honeywell
FIGURE 3-34 DO EMR connections
JPx
N/O N/C
SPST
Configurable as N/O or N/C
via jumper
SPST
Configurable as N/O or N/C
via jumper
CNx
1,3,5,7 [EMRx_no]
2,4,6,8 [EMR_common]
1,3,5,7 [EMRx_no]
2,4,6,8 [EMR_common]
CAN-IN-OUT-MSC
External
DC PSU
LOAD
External equipment
CAN-IN-OUT-MSC External equipment
+
-
JPx
N/O N/C
CNx
AC
L
N
3A(T)
LOAD
