GASLAB Q2 DISPLAYS (OPERATE THE DEVICE)
Information for general use
Rev. M / 73023639
If a user is logged in with the appropriate rights, the basic network settings can be changed in the
Ethernet I/F (Ethernet interface) display, see the figure below.
Figure 7.40: I/O displays with options to make an entry and restart
The setting of the IP address and the basic network settings is
not only via the operationn panel but also via enSuite.
For more information, see section 8.4.5 Changing the IP address basic network and
I/O settings and the enSuite online help,
which also explains the various settings in more details
Do not change the configuration settings (DHCP mode).
(Only relevant for service personnel.)
Ne modifiez pas les paramètres de configuration (mode DHCP), car cette fonction ne
concerne que le service!
Action: Viewing/Editing basic network settings
Log in ( see section 7.3.11 System display Users (Login/Logout / Password)) and
navigate to “System” I/O Overview display and click on CPU3.
Make a note of the settings and select the entry you wish to edit.
If necessary, ask your system administrator which parameters must be edited.
(When an entry is selected, the keypad will be displayed.)
Use the keyboard to enter the values specified (by the system administrator) input box
by input box.
When you have made all the changes, you must restart the device using the displayed
action [Ok&Reboot] (see figure). The edited data will then be used after the restart.
If you exit the display using , your changes will not be saved.
