GASLAB Q2 DISPLAYS (OPERATE THE DEVICE)
Information for general use
Rev. M / 73023639
7.3.15. Display Q2 sensor values
The list of sensor values can be opened by clicking on this symbol.
Generally, this display is only used for service purposes and for locating errors.
Figure 7.41:
Q2 sensor values display
A complete list of all sensor values is displayed in the following table:
For internal calculations only
For internal calculations only
For internal calculations only
For internal calculations only
Pressure (ambient + measuring unit [approx.
160 mbar])
Temperature of sensor block
approx. 70°C ≙ 158°F ≙ 343K
For internal calculations only
For internal calculations only
For internal calculations only
For internal calculations only
Ambient pressure (internal monitoring)
Circuit board pressure (internal monitoring)
For internal calculations only
For internal calculations only
For internal calculations only
For internal calculations only
For internal calculations only
For internal calculations only
Housing temperature (internal monitoring)
