CONFIGURATION AND ANALYSIS SOFTWARE ENSUITE
Information for general use
Rev. M / 73023639
8.2.4. Establish a connection to the enCore device
The connection to one or more devices can be made in various ways, for example select one of the
following symbols on the button bar shown in the table.
Actions –
Search device
(alternatively press
the [F3] key)
Searches for all accessible devices and establishes the
connection. All devices which were unknown up until now are
entered in the enSuite database.
This option is recommended for all initial connections
established with one or more devices.
Establishes the connection to a specific device. The device must
be contained already in the enSuite database and selected in
the navigation window under the Devices branch (identification
via serial number).
The first icon contains a search function, e.g. for connecting devices (new devices) that are not yet
available in the database. After a first connection the individual devices are identified and stored in
the enSuite database by their serial number; for such devices, the second symbol can be used.
In both cases, a dialog to select the connection path then appears once the option is activated
Figure 8.5: Dialogs Search device and connect and Connect (examples)
