CONFIGURATION AND ANALYSIS SOFTWARE ENSUITE
Information for general use
Rev. M / 73023639
8.2.6. Read-out parameterization
There must be an active data connection to the device (ļ° sections 8.2.3 and 8.2.4) before the para-
metrization can be read-out from the device.
Read the parameter set after making any changes.
Save every changed parameter set as a backup separately for emergencies
and, if necessary, export it to an external PC/external data medium.
enSuite will not automatically back up the parameter set!
If a connection exists, proceed as follows:
1. Highlight the device in question in the navigation window either under the Devices branch
or under the Connections branch.
2. Select the action Read out parameterization in the lower section of the navigation window
or open the context menu and select āReadout parameterizationā. A dialog "Save as" will
appear.
Figure 8.14: Save as dialog
3. If necessary, you can now change the displayed name by overwriting it. Then press [OK].
Some devices transfer sensitive data,
for the Q2 it is not nessesary to mark the checkbox. You can confirm with [OK].
If the checkbox is selected a login dialog will appear after pressing [OK] button.
See section 8.3 User management and login for more details about login.
