GASLAB Q2 AFTER DELIVERY AND AT THE PLACE OF USE
Information for general use
Rev. M / 73023639
5.2. Mechanical installation of GasLab Q2
Select an installation height between 1.10 m ≙ 3.608ft and 1.8m ≙ 5.906ft above the floor which is
suitable for operation and reading. An empty space with minimum dimensions of 270 mm ≙ 10.63
inch wide and 500 mm ≙ 19.69 inch long in the field of view must be available. We also recommend
a space at the side to make installation and maintenance work easier.
Prevent dirt and / or moisture from entering the device during work and possibly causing damage.
5.2.1. Place of use and installation
Obey the explosion-protection rules at all times when working with tools or on items in
hazardous zones. Prenez note qu’il est essentiel de toujours suivre les règles de
protection contre les explosions lorsque vous travaillez avec des outils ou sur des objets
dans les zones à risque d’explosion.
The GasLab Q2 must be installed as close as possible to the process gas sampling point to avoid
having long supply lines and to ensure that you obtain current measurements.
The measurement device weighs around 16 kg ≙ 36 lb. Before installing it, ensure that the
installation surface is strong enough to support it.
The installation site must meet the safety conditions. Le site d'installation doit répondre aux
conditions de sécurité. 2.2 Place of use Environmental conditions and installation
The sand guard (HMI cover) should be screwed on in sandy environments. Please contact
Honeywell for further information. La protection contre le sable (couvercle de l'IHM) doit
être vissée dans les environnements sableux. Veuillez contacter Honeywell pour de plus
amples informations.
GasLab Q2 does not require a special mounting plate since the measurement device contains all
the parts required for the measuring task in its explosion-protected housing. It may be installed on
a flat vertical surface (wall/measuring board).
Use the 8 mm ≙ 0.31 inch fastening holes provided in the housing for this purpose. Use size M8
(minimum M6) fastening material or equivalent in all four fastening holes to secure the device.
Suitable complements (in other words, nuts or anchors) depend on the material and the type of
installation surface. The material to which the GasLab Q2 is fastened must withstand a combined
vertical load of 1000 N ≙ 224.809 lbf at the four fastening points.
.
GasLab Q2 must be installed so that the main breather element points downwards and the
cable connections point upwards. Le GasLab Q2 doit être installé de telle sorte que le
dispositif d’évent principal soit orienté vers le bas et les presse-étoupes vers le haut.
