The dialog “Search device and connect” also allows the selection
of other device types. For proChain GC select the type as shown in the figure above
• To establish a USB connection, select Local connection; this can only be used when the
instrumentation section is open, see section 6.1.3 Opening and closing the hardware
parameter guard (SSW). After selecting confirm with [OK].
• For a TCP-IP connection, select select Remote connection - in this case, the network name or IP
address of the enCore device is required. This can be found on the I/O display under CPU 3 on
the device. You can access the display via Home and System. If necessary, adjust these settings
as described in Chapter 7. After selecting and filling in the fields, confirm with [OK].
See also the following example to establish the first connection with a device not registered in the
database
1. select the corresponding function e.g. in the navigation window or on the button bar
2. enter the connection data in the dialog, (see next figure) and confirm with [OK]
Figure 8.6: Find and Connect Device (enSuite Window)
