STRUCTURE AND INSCRIPTIONS OF THE GASLAB Q2
Information for general use
Rev. M / 73023639
In addition, the type labeles contain information about the approvals granted and the explosion
protection properties. Not all certificates and approvals are listed in this documentation. The
following table shows a selection.
Approvals (selection) Only the specifications on the respective device apply!
(For EU) Approval number DEKRA 15.ATEX0113X /IECEx DEK 15.0075X
CE mark with auditor number
Approval number FM: FM17US0040X/FM17CA0027X Class I Div 2 Groups ABCD T4
Ex rating: (II 2G) (A) Ex db IIC T4 Gb (for ATEX IECEx and FM)
Depending on application, measuring ranges of the evaluation certificate according to OIML R 140
for calorific value determining devices could be also mentioned. Figure 3.6 shows examples of main
type plates and a metrological type plate (bottom right).
Figure 3.6: Type labeles (examples)
