Table 51 Processor Events That Light Diagnostic Panel LEDs (continued)
NotesSourceCauseSample IPMI EventsDiagnostic
LEDs
Threshold exceeded
for cache errors from
WIN
Agent
Too many
corrected errors
Type E0h, 5824d:26d PFM_CORR_ERROR_MEMProcessors
processor corrected
by zx2
detected by
platform
Power Pod voltage is
out of range (likely
too low)
BMCVoltage on FRU is
inadequate
Type 02h, 02h:07h:03h
VOLTAGE_DEGRADES_TO_NON_RECOVERABLE
Processors
A voltage on the
processor carrier is
BMCVoltage on FRU is
inadequate
Type 02h, 02h:07h:03h
VOLTAGE_DEGRADES_TO_NON_RECOVERABLE
Processor
Carrier
out of range (likely
too low)
Table 52 lists the processor events that may light the diagnostic panel LEDs.
Table 52 Processor Events That May Light Diagnostic Panel LEDs
NotesSourceCauseSample IPMI EventsDiagnostic
LED(s)
SFWInstalled
processors
Type E0h, 734d:26d BOOT_CPU_LOADING_ERRORProcessors
are not
compatible
SFWProcessors
and/or
Type E0h, 2953d:26d BOOT_CPU_LOADING_ERRORProcessors
termination
out of order
SFWA logical CPU
(thread) failed
late self test
Type E0h, 36d:26d BOOT_CPU_LATE_TEST_FAILProcessors
SFWA logical CPU
(thread) slave
Type E0h, 677d:26d MC_RENDEZVOUS_SLAVES_FAILProcessors
failed to
rendezvous
SFWA CPU core
failed the
Type E0h, 30d:26d BOOT_CPU_CONFIG_FAILProcessors
configuration
process
SFWA processor’s
fixed core
Type E0h, 790d:26d BOOT_CPU_BAD_CORE_FIXED_RATIOProcessors
frequency
ratio is
incompatible
with bus
frequency
SFWA watchdog
timer expired
Type E0h, 745d:26d
BOOT_FINAL_RENDEZ_WATCHDOG_FAIL
Processors
and
determined
that a
monarch
processor is
not
responding.
Bad or slow
processor
SFWA logical CPU
(thread)
Type E0h, 83d:26d BOOT_RENDEZ_FAILUREProcessors
