Table 71 PCI/PCI-X/PCIe I/O Paths (continued)
EFI Device PathHP-UX Device PathLocation
as
viewed
from
rear of
chassis
Function
Associated
with Path
Slot
Optional
SAS core
I/O card
Acpi(HPQ0002,PNP0A08,700)/Pci(0|0)/Pci(0|*)0/7/0/0/0/*5th from
left
I/O PCIe
x8
5
Acpi(HPQ0002,PNP0A08,300)/Pci(0|0)/Pci(0|*)0/3/0/0/0/*6th from
left
I/O PCIe
x8
6
Acpi(HWP0002,PNP0A03,200)/Pci(1|*)0/2/1/*7th from
left
I/O 133
MHz
7
64-bit
PCI-X card
Acpi(HWP0002,PNP0A03,500)/Pci(1|*)0/5/1/*8th from
left
I/O 133
MHz
8
64-bit
PCI-X card
Acpi(HWP0002,PNP0A03,100)/Pci(1|*)0/1/1/*9th from
left
I/O with
66 MHz
9
64-bit
PCI-X card
(shared
with slot
10)
Acpi(HWP0002,PNP0A03,100)/Pci(2|*)0/1/2/*10th
from left
I/O with
66 MHz
10
( nearest64-bit
to corePCI-X card
I/O
board)
(shared
with slot
9)
Acpi(HWP0002,PNP0A03,0)/Pci(1|*)0/0/1/*Right
most
Core I/O
iLO 2 MP
Core
I/O
board special
slot
Acpi(HWP0002,PNP0A03,0)/Pci(2|*)0/0/2/*Right
most
Core I/O
USB
Core
I/O
board special
slot
Acpi(HWP0002,PNP0A03,0)/Pci(4|*)0/0/4/*Right
most
Core I/O
VGA
(optional)
Core
I/O
board special
slot
Removing and Replacing a Hot-Pluggable PCI/PCI-X/PCIe Card 197

HP Integrity rx6600 Specifications

General

Processor	Intel Itanium 2
Network	Integrated dual Gigabit Ethernet
Form Factor	5U rack-mountable
Power Supply	Redundant hot-plug power supplies
Processor Speed	1.6 GHz
Memory Type	DDR2 ECC Registered
RAID Support	Yes
Operating System	HP-UX, Linux, Windows Server
