Table 70 PCI/PCI-X I/O Paths (continued)
EFI Device PathHP-UX
Device
Path
Location (as viewed from
rear of chassis)
Function with PathSlot
Acpi(HWP0002,200)/Pci(1*)0/2/1/*6th from left (public)I/O with 133 MHz/
64 bit PCI-X card
6
Acpi(HWP0002,500)/Pci(1*)0/5/1/*7th from left (public)I/O with 66 MHz/ 64
bit PCI-X card (shared
with slot 8)
7
Acpi(HWP0002,500)/Pci(2*)0/5/2/*8th from left (public)I/O with 66 MHz/ 64
bit PCI-X card (shared
with slot 7)
8
Acpi(HWP0002,100)/Pci(1*)0/1/1/*9th from left (public)I/O with 66 MHz/ 64
bit PCI-X card (shared
with slot 10)
9
Acpi(HWP0002,100)/Pci(2*)0/1/2/*10th from left (public;
nearest to core I/O
board)
I/O with 66 MHz/ 64
bit PCI-X card (shared
with slot 9)
10
Acpi(HWP0002,0)/Pci(1*)0/0/1/*Right-most special slot
(private)
Core I/O iLO 2 MPCore I/O board
Acpi(HWP0002,0)/Pci(2*)0/0/2/*Right-most special slot
(private)
Core I/O USB
Acpi(HWP0002,0)/Pci(4*)0/0/4/*Right-most special slot
(private)
Core I/O VGA
(optional)
Table 71 PCI/PCI-X/PCIe I/O Paths
EFI Device PathHP-UX Device PathLocation
as
Function
Associated
with Path
Slot
viewed
from
rear of
chassis
Acpi(HWP0002,PNP0A03,400)/Pci(1|*)0/4/1/*Left-most
slot (
SAS core
I/O card
1
nearest
to power
supply)
Acpi(HWP0002,PNP0A03,400)/Pci(2|*)0/4/2/*2nd from
left
Dual port
Gigabit
2
LAN
(Core I/O
LAN)
Acpi(HPQ0002,PNP0A08,600)/Pci(0|0)/Pci(0|0)/Pci(1|0)/Pci(0|*)
1
0/6/0/0/0/0/1/0/0/*
1
3rd from
left
I/O PCIe
x8
3
(switched
with slot
4)
Optional
SAS core
I/O card
Acpi(HPQ0002,PNP0A08,600)/Pci(0|0)/Pci(0|0)/Pci(0|0)/Pci(0|*)0/6/0/0/0/0/0/0/0/*
1
4th from
left
I/O PCIe
x8
4
1
(switched
with slot
3)
196 Removing and Replacing Server Components

HP Integrity rx6600 Specifications

General

Processor	Intel Itanium 2
Network	Integrated dual Gigabit Ethernet
Form Factor	5U rack-mountable
Power Supply	Redundant hot-plug power supplies
Processor Speed	1.6 GHz
Memory Type	DDR2 ECC Registered
RAID Support	Yes
Operating System	HP-UX, Linux, Windows Server
