Flow interval configuration
Overview
With the flow interval module, you can view the number of packets and bytes sent/received by a port over
the specified interval.
Monitoring port traffic statistics
Setting the traffic statistics generating interval
Select Device Flow interval from the navigation bar, and click the Interval Configuration tab to enter the
page shown in a.
a. The page for setting the traffic statistics generating interval
2. Traffic statistics generating interval configuration items
Item Remarks
Interval for generating traffic statistics
Set the interval for generating port traffic statistics.
Select ports
Select ports from the chassis front panel to apply the interval
to them.
Viewing port traffic statistics
Select Device Flow interval from the navigation tree to enter the Port Traffic Statistics tab shown in a. On
the tab, you can view the number of packets and bytes sent/received by each port over the last interval.
