Item Descri
p
tion
Unit of Packets
Specify the unit for data packets sent to the RADIUS server, which
can be
 one-packet
 kilo-packet
 mega-packet
 giga-packet
3. Relationship between the real-time accounting interval and the number of users
Number of users Real-time accountin
g
interval (in minutes)
1 to 99 3
100 to 499 6
500 to 999 12

1000

15
Return to RADIUS configuration task list.
RADIUS configuration example
Network requirements
As shown in a, configure the switch to let the RADIUS server authenticate and keep accounts on the user
(record the online duration of the Telnet user).
On the RADIUS server (a CAMS or iMC server, using the default port for authentication and accounting), the
Telnet user’s username and password and the shared key expert have been configured for packet
exchange with the switch.
On the switch, it is required to configure the shared key for packet exchange with the RADIUS server as
expert, and configure the system to remove the domain name of a username before sending it to the
RADIUS server.
a. Network diagram for RADIUS server configuration
Configuration procedure
NOTE:
Enable the Telnet server function, and configure the switch to use AAA for authentication, authorization
and accounting of Telnet users.Detailed configuration steps are omitted here.
Table 136 Configure IP addresses for the interfaces. Detailed configuration steps are omitted here.
Table 137 Configure RADIUS scheme system

HP V1910 Specifications

General

Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Manageable	Yes
Form Factor	Rack-mountable
Features	VLAN, QoS, Link Aggregation
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000 + 4 x SFP
