434
1.
Priority mapping table configuration task list
Task Remarks
Configuring priority mapping tables
Required
Set priority mapping tables.
Configuring priority trust mode
Perform the task in 1 to configure priority trust mode:
1. Priority trust mode configuration task list
Task Remarks
Configuring priority trust mode on a port
Required
Set the priority trust mode of a port.
Creating a class
Select QoS Classifier from the navigation tree and click Create to enter the page for creating a class, as
shown in a.
a. The page for creating a class
2 shows the configuration items of creating a class.
2. Configuration items of creating a class
Item Descri
tion
Classifier Name
Specify a name for the classifier to be created.
Operator
Specify the operator for the match criteria of the classifier.
and—A packet must match all the criteria to match the class.
or—A packet matches the class if it matches any of the criteria in the class.
