414
Item Descri
p
tion
To
Set the end time and date of the absolute time range. The time
of the day is in the hh:mm format (24-hour clock), and the date
is in the MM/DD/YYYY format. The end time must be greater
than the start time.
of the week
only within the
specified
period.
Return to IPv4 ACL configuration task list.
Creating an IPv4 ACL
Select QoS  ACL IPv4 from the navigation tree and then select the Create tab to enter the IPv4 ACL
configuration page, as shown in a.
a. The page for creating an IPv4 ACL
2 describes the configuration items for creating an IPv4 ACL.
2. IPv4 ACL configuration items
Item Descri
p
tion
ACL Number Set the number of the IPv4 ACL.
Match Order
Set the match order of the ACL. Available values are:
 Config—Compare packets against ACL rules in the order that the rules are
configured.
 Auto—Compares packets against ACL rules in the depth-first match order.
Return to IPv4 ACL configuration task list.
Configuring a rule for a basic IPv4 ACL
Select QoS  ACL IPv4 from the navigation tree and then select the Basic Setup tab to enter the rule
configuration page for a basic IPv4 ACL, as shown in a.
