Page #76 background imageLoading...
Page #76 background image
64
Downloading a file
Select Device File Management from the navigation tree to enter the file management page, as shown in
a. Select a file from the list, click the Download File button, and then a File Download dialog box appears.
You can select to open the file or to save the file locally, and you can download only one file at a time.
Uploading a file
Select Device File Management from the navigation tree to enter the file management page, as shown in
a. In the Upload File area, select a disk from the Please select disk drop-down list to save the file, and then
select the file path and filename by clicking Browse. Click Apply to upload the file to the specified storage
device.
CAUTION:
Uploading a file takes some time. HP recommends you not to perform any operation on the web interface
during the upgrading procedure.
Removing a file
Select Device File Management from the navigation tree to enter the file management page, as shown in
a. You can remove a file by using one of the following ways:
Click the
icon to remove a file.
Select one or multiple files from the file list, and then click Remove File.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP V1910 and is the answer not in the manual?

HP V1910 Specifications

General IconGeneral
Switching Capacity56 Gbps
Forwarding Rate41.7 Mpps
ManageableYes
Form FactorRack-mountable
FeaturesVLAN, QoS, Link Aggregation
Operating Temperature0°C to 45°C
Operating Humidity10% to 90% (non-condensing)
Ports24 x 10/100/1000 + 4 x SFP
