268
Creating an IPv4 static route
Select Network IPv4 Routing from the navigation tree and click the Create tab to enter the IPv4 static route
configuration page, as shown in a.
a. Create an IPv4 static route
2. IPv4 static route configuration items
Item Descri
p
tion
Destination IP Address
Type the destination IP address of the static route, in dotted decimal notation.
Mask
Specify the mask of the destination IP address.
Select a mask length (number of consecutive 1s in the mask) or a mask in
dotted decimal notation from the drop-down list.
Preference
Type a preference value for the static route. The smaller the number, the higher
the preference.
For example, specifying the same preference for multiple static routes to the
same destination enables load sharing on the routes; specifying different
preferences enables route backup.
Next Hop Type the next hop IP address, in dotted decimal notation.
