HP V1910 User Manual

117
Task Remarks
Configuring SNMP trap
Optional
Allows you to configure that the agent can send SNMP traps to the
NMS, and configure information about the target host of the SNMP
traps.
By default, an agent is allowed to send SNMP traps to the NMS.
Configuring SNMPv3
Perform the tasks in 1 to configure SNMPv3:
1. SNMPv3 configuration task list
Task Remarks
Enabling SNMP
Required
The SNMP agent function is disabled by default.
Configuring an SNMP
Optional
After creating SNMP views, you can specify an SNMP view for an
SNMP group to limit the MIB objects that can be accessed by the SNMP
group.
Configuring an SNMP
Required
After creating an SNMP group, you can add SNMP users to the group
when creating the users. Therefore, you can realize centralized
management of users in the group through the management of the
group.
Configuring an SNMP
Required
Before creating an SNMP user, you need to create the SNMP group to
which the user belongs.
Configuring SNMP trap
Optional
Allows you to configure that the agent can send SNMP traps to the
NMS, and configure information about the target host of the SNMP
traps
By default, an agent is allowed to send SNMP traps to the NMS.
Enabling SNMP
Select Device  SNMP from the navigation tree to enter the SNMP configuration page, as shown in a. On
the upper part of the page, you can select to enable or disable SNMP and configure parameters such as
SNMP version; on the lower part of the page, you can view the SNMP statistics, which helps you
understand the running status of the SNMP after your configuration.

HP V1910 Specifications

General

Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Manageable	Yes
Form Factor	Rack-mountable
Features	VLAN, QoS, Link Aggregation
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000 + 4 x SFP
