HP V1910 User Manual

122
2. Configuration items for configuring an SNMP community
Item Descri
p
tion
Community Name Set the SNMP community name.
Access Right
Configure SNMP NMS access right
 Read only—The NMS can perform read-only operations to the MIB objects when
it uses this community name to access the agent,
 Read and write—The NMS can perform both read and write operations to the MIB
objects when it uses this community name to access the agent.
View
Specify the view associated with the community to limit the MIB objects that can be
accessed by the NMS.
ACL
Associate the community with a basic ACL to allow or prohibit the access to the agent
from the NMS with the specified source IP address.
Return to SNMPv1 or SNMPv2c configuration task list.
Configuring an SNMP group
Table 32 Select Device  SNMP from the navigation tree.
Table 33 Click the Group tab to enter the page as shown in b.
Table 34 Click Add to enter the Add SNMP Group page as shown in c.
b. SNMP group

HP V1910 Specifications

General

Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Manageable	Yes
Form Factor	Rack-mountable
Features	VLAN, QoS, Link Aggregation
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000 + 4 x SFP
