HP V1910 User Manual

309
Creating a static ARP entry
Select Network  ARP Management from the navigation tree to enter the default ARP Table page shown in
a. Click Add to enter the New Static ARP Entry page. Select the Advanced Options checkbox to expand
advanced configuration items, as shown in a.
a. Add a static ARP entry
2 describes the static ARP entry configuration items.
2. Static ARP entry configuration items
Item Descri
p
tion
IP Address Type an IP address for the static ARP entry.
MAC Address Type a MAC address for the static ARP entry.
Advanced
Options
VLAN ID
Type a VLAN ID and specify a port for the static ARP entry.
IMPORTANT:
The VLAN ID must be the ID of the VLAN that has already been created, and the port
must belong to the VLAN. The corresponding VLAN interface must have been created.
Port
Static ARP configuration example
Network requirements
As shown in a, hosts are connected to Switch A, which is connected to Router B through interface
GigabitEthernet 1/0/1 belonging to VLAN 100. The IP address of Router B is 192.168.1.1/24. The MAC
address of Router B is 00e0-fc01-0000.
To enhance communication security between Switch A and Router B, static ARP entries need to be
configured on Switch A.

HP V1910 Specifications

General

Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Manageable	Yes
Form Factor	Rack-mountable
Features	VLAN, QoS, Link Aggregation
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000 + 4 x SFP
