HP V1910 User Manual

324
The access device supports the following modes:
 Multicast trigger mode—The access device multicasts Identity EAP-Request packets periodically (every
30 seconds by default) to initiate 802.1X authentication.
 Unicast trigger mode—Upon receiving a frame with the source MAC address not in the MAC address
table, the access device sends an Identity EAP-Request packet out of the receiving port to the unknown
MAC address. It retransmits the packet if no response has been received within a certain time interval.
802.1X authentication procedures
802.1X authentication has two approaches: EAP relay and EAP termination. You choose either mode
depending on the support of the RADIUS server for EAP packets and EAP authentication methods.
EAP relay is defined in IEEE 802.1X. In this mode, the network device uses EAPoR packets to send
authentication information to the RADIUS server, as shown in a.
a. EAP relay
In EAP termination mode, the network access device terminates the EAP packets received from the client,
encapsulates the client authentication information in standard RADIUS packets, and uses Password
Authentication Protocol (PAP) or Challenge Handshake Authentication Protocol (CHAP) to authenticate to
the RADIUS server, as shown in b.
b. EAP termination
A comparison of EAP relay and EAP termination
Packet exchan
g
e method Benefits Limitations
EAP relay
 Supports various EAP
authentication methods.
 The configuration and processing
is simple on the network access
device
The RADIUS server must support the
EAP-Message and
Message-Authenticator attributes,
and the EAP authentication method
used by the client.

HP V1910 Specifications

General

Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Manageable	Yes
Form Factor	Rack-mountable
Features	VLAN, QoS, Link Aggregation
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000 + 4 x SFP
