HP V1910 User Manual

142
Modifying ports
Select Network  VLAN from the navigation tree and click the Modify Port tab to enter the page shown in
a.
a. The Modify Port tab
2. Configuration items of modifying ports
Item Descri
p
tion
Select Ports
Select the ports to be modified.
Click one or more ports you want to modify on the chassis front panel.
If aggregate interfaces are configured on the device, the page displays a list of
aggregate interfaces below the chassis front panel, and you can select
aggregate interfaces from this list.
Select
membership
type
Untagged
Set the member types of the selected ports to be modified in the specified VLANs.
The options include:
 Untagged—Assign the selected ports to the specified VLANs as untagged
members. After that, the ports send the traffic of those VLANs after removing
the VLAN tags.
 Tagged—Assign the selected ports to the specified VLANs as tagged
members. After that, the ports send the traffic of those VLANs without
removing the VLAN tags.
 Not A Member—Remove the selected ports from the specified VLANs.
Tagged
Not A
Member

HP V1910 Specifications

General

Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Manageable	Yes
Form Factor	Rack-mountable
Features	VLAN, QoS, Link Aggregation
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000 + 4 x SFP
