208
○ The number of selected ports that an aggregation group can contain is limited. When the number
of candidate selected ports is under the limit, all the candidate selected ports are set to Selected
state. When the limit is exceeded, the system selects the candidate selected ports with smaller port
IDs as the selected ports, and set other candidate selected ports to Unselected state. At the same
time, the peer device, being aware of the changes, changes the state of its ports accordingly.
Table 53 Set the ports that cannot aggregate with the reference port to the Unselected state.
NOTE:
For static and dynamic aggregation modes:
In an a
re
ation
roup, the port to be a selected port must be the same as the reference port in por
attributes, and class-two confi
urations. To keep these confi
urations consistent, you should manuall
configure the port.
Change a port attribute or class-two configuration setting for a port with caution, because the chan
e
may affect the aggregation state of member ports and interrupt services.
Load sharing mode of an aggregation group
Every link aggregation group created on HP V1910 Switch Series operates in load sharing mode all the
time, even when it contains only one member port.
Configuring link aggregation and LACP
Configuration task list
Configuring a static aggregation group
Perform the tasks in 1 to configure a static aggregation group.
1. Static aggregation group configuration task list
Task Remarks
Creating a link aggregation group
Required
Create a static aggregate interface and configure member
ports for the static aggregation group automatically created
by the system when you create the aggregate interface.
By default, no link aggregation group exists.
Displaying information of an aggregate
interface
Optional
Perform this task to view detailed information of an existing
aggregation group.
Configuring a dynamic aggregation group
Perform the tasks in 1 to configure a dynamic aggregation group.
