HP V1910 User Manual

432
2.
The default DSCP to CoS/DSCP to Queue mapping table
Input DSCP value Local precedence (Queue) CoS
0 to 7 0 0
8 to 15 1 1
16 to 23 2 2
24 to 31 3 3
32 to 39 4 4
40 to 47 5 5
48 to 55 6 6
56 to 63 7 7
NOTE:
In the default DSCP to DSCP mapping table, an input value yields a target value equal to it.
QoS configuration
Configuration task lists
Configuring a QoS policy
A QoS policy defines the shaping, policing, or other QoS actions to take on different classes of traffic. It is
a set of class-behavior associations.
A class is a set of match criteria for identifying traffic, and it uses the AND or OR operator:
 If the operator is AND, a packet must match all the criteria to match the class.
 If the operator is OR, a packet matches the class if it matches any of the criteria in the class.
A traffic behavior defines a set of QoS actions to take on packets, such as priority marking and redirect.
By associating a traffic behavior with a class in a QoS policy, you apply the specific set of QoS actions to
the class of traffic. You can apply a QoS policy to a port to regulate the incoming traffic of the port. A QoS
policy can be applied to multiple ports. Only one policy can be applied in inbound direction of a port.
Perform the tasks in 1 to configure a QoS policy:
1. QoS policy configuration task list
Task Remarks
Configure a
class
Creating a class
Required
Create a class and specify the operator for
the match criteria in the class.
Configuring match criteria
Required
Configure match criteria for the class.

HP V1910 Specifications

General

Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Manageable	Yes
Form Factor	Rack-mountable
Features	VLAN, QoS, Link Aggregation
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000 + 4 x SFP
