438
Configuring traffic mirroring and traffic redirecting for a traffic
behavior
Select QoS Behavior from the navigation tree and click Port Setup to enter the port setup page for a traffic
behavior, as shown in a.
a. Port setup page for a traffic behavior
2 describes the traffic mirroring and traffic redirecting configuration items.
2. Traffic mirroring and traffic redirecting configuration items
Item Descri
p
tion
Please select a behavior
Select an existing behavior in the drop-down list.
Redirect
Set the action of redirecting traffic to the specified destination port.
Please select a port
Specify the port to be configured as the destination port of traffic mirroring or
traffic directing on the chassis front panel.
Return to QoS policy configuration task list.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP V1910 and is the answer not in the manual?

HP V1910 Specifications

General IconGeneral
Switching Capacity56 Gbps
Forwarding Rate41.7 Mpps
ManageableYes
Form FactorRack-mountable
FeaturesVLAN, QoS, Link Aggregation
Operating Temperature0°C to 45°C
Operating Humidity10% to 90% (non-condensing)
Ports24 x 10/100/1000 + 4 x SFP
