HP V1910 User Manual

Item Descri
p
tion
Primary Server Status
Set the status of the primary server, including:
 active: The server is working normally.
 blocked: The server is down.
If the IP address of the primary server is not specified or the specified IP address
is to be removed, the status is blocked.
Secondary Server IP
Specify the IP address of the secondary server.
If no secondary server is specified, the text box displays 0.0.0.0.
To remove the previously configured secondary server, enter 0.0.0.0 in the text
box.
The specified IP address of the secondary server cannot be the same as that of
the primary server.
Secondary Server UDP Port
Specify the UDP port of the secondary server.
If the IP address of the secondary server is not specified or the specified IP
address is to be removed, the port number is 1812 for authentication or 1813
for accounting.
Secondary Server Status
Status of the secondary server, including:
 active: The server is working normally.
 blocked: The server is down.
If the IP address of the secondary server is not specified or the specified IP
address is to be removed, the status is blocked.
Return to RADIUS configuration task list.
Configuring RADIUS parameters
From the navigation tree, select Authentication  RADIUS and then select the RADIUS Setup tab to enter the
RADIUS parameter configuration page, as shown in a.

HP V1910 Specifications

General

Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Manageable	Yes
Form Factor	Rack-mountable
Features	VLAN, QoS, Link Aggregation
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000 + 4 x SFP
