Basic system information
The INFO area on the right of the page displays the basic system information such as device name, product
information, device location, contact information, serial number, software version, hardware version, Boot
ROM version, and running time. The running time displays how long the device is up since the last boot.
You can configure the device location and contact information on the Setup page you enter by selecting
Device SNMP.
System resource state
The System Resource State displays the latest CPU usage and memory usage.
Recent system operation logs
1. Description about the recent system operation logs
Field Descri
tion
Time Displays the time when the system operation logs are generated.
Level Displays the severity of the system operation logs.
Description Displays the description of the system operation logs.
NOTE:
The Summary page displays up to five latest system operation lo
s about the lo
in and lo
out events.
For more system operation logs, click More to enter the Log List pa
e. You can also enter this pa
e by
selecting Device Syslog. For more information, see the chapter “Log management configuration”.
Displaying device information
After logging in to the web interface, you can click the Device Information tab to enter the page displaying
the device ports. Hover the cursor over a port and the port details appears, including the port name, type,
speed, utilization, and status, as shown in a. For the description about the port number and its color, see a.
Similarly, you can view the power type and working status and the fan working status.
