69
Item Descri
tion
Selected Ports
Port or ports that you have selected from the chassis front panel and the
aggregate interface list below, for which you have set operation parameters.
IMPORTANT:
Only in the presence of link aggregations groups, Aggregation ports will
be displayed under the chassis front panel.
You can set only the state and MAC learning limit for an aggregate
interface.
Viewing the operation parameters of a port
Select Device Port Management from the navigation tree. The Summary tab is displayed by default.
Select the parameter you want to view by clicking the radio button before it to display the setting of this
parameter for all the ports in the lower part of the page, as shown in a.
a. The Summary tab
Select Device Port Management from the navigation tree, select the Details tab on the page that appears,
and then click the port whose operation parameters you want to view in the chassis front panel, as shown
in b. The operation parameter settings of the selected port are displayed on the lower part of the page (in
the square brackets).
