Task Remarks
Configure a
traffic
behavior
Creating a traffic behavior
Required
Create a traffic behavior.
Configuring actions
for a behavior
Configuring traffic
mirroring and traffic
redirecting for a
traffic behavior
Use either approach
Configure various actions for the traffic
behavior.
Configuring other
actions for a traffic
behavior
Configure a
policy
Creating a policy
Required
Create a policy.
Configuring classifier-behavior associations
for the policy
Required
Associate the traffic behavior with the class
in the QoS policy.
A class can be associated with only one
traffic behavior in a QoS policy. Associating
a class that is already associated with a
traffic behavior will overwrite the old
association.
Apply the
policy
Applying a policy to a port
Required
Apply the QoS policy to a port.
Configuring queue scheduling
Perform the task in 1 to configure queue scheduling.
1. Queue scheduling configuration task list
Task Remarks
Configuring queue scheduling on a port
Optional
Configure the queue scheduling mode for a port.
Configuring line rate
Perform the task in 1 to configure line rate.
1. Line rate configuration task list
Task Remarks
Configuring line rate on a port
Required
Limit the rate of incoming packets or outgoing packets
of a physical port.
Configuring the priority mapping tables
Perform the task in 1 to configure the priority mapping tables:
