HP V1910 User Manual

234
Field Descri
p
tion
Port ID type
Port ID type:
 Interface alias
 Port component
 MAC address
 Network address
 Interface name
 Agent circuit ID
 Locally assigned—Local configuration.
Port ID The port ID value.
System capabilities supported
The primary network function of the system:
 Repeater
 Bridge
 Router
System capabilities enabled
The network function enabled on the system:
 Repeater
 Bridge
 Router
Auto-negotiation supported The support of the neighbor for auto negotiation.
Auto-negotiation enabled The enable status of auto negotiation on the neighbor.
OperMau Current speed and duplex mode of the neighbor.
Link aggregation supported The neighbor supports link aggregation.
Link aggregation enabled Link aggregation is enabled on the neighbor.
Aggregation port ID
Link aggregation group ID. It is 0 if the neighbor port is not assigned to any
link aggregation group.
Maximum frame Size The maximum frame size supported on the neighbor port.
Device class
MED device type:
 Connectivity device—An intermediate device that provide network
connectivity.
 Class I—a generic endpoint device. All endpoints that require the
discovery service of LLDP belong to this category.
 Class II—A media endpoint device. The class II endpoint devices support
the media stream capabilities in addition to the capabilities of generic
endpoint devices.
 Class III—A communication endpoint device. The class III endpoint
devices directly support end users of the IP communication system.
Providing all capabilities of generic and media endpoint devices, Class
III endpoint devices are used directly by end users.

HP V1910 Specifications

General

Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Manageable	Yes
Form Factor	Rack-mountable
Features	VLAN, QoS, Link Aggregation
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000 + 4 x SFP
