HP V1910 User Manual

287
 Click Apply.
# Enable the DHCP relay agent on VLAN-interface 1.
 In the Interface Config field, click the
icon of VLAN-interface 1, and then perform the following
operations, as shown in d.
d. Enable the DHCP relay agent on an interface and correlate it with a server group
 Click on the Enable radio button next to DHCP Relay.
 Select 1 for Server Group ID.
 Click Apply.
NOTE:
Because the DHCP relay agent and server are on different subnets, you need to configure a static route o
r
dynamic routing protocol to make them reachable to each other.

HP V1910 Specifications

General

Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Manageable	Yes
Form Factor	Rack-mountable
Features	VLAN, QoS, Link Aggregation
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000 + 4 x SFP
