PANEL FUNC 11: B467____ 5200245E
81009300 00000000
PANEL FUNC 12: xxxxxxxx xxxxxxxx
319725AA 00000000
PANEL FUNC 13: xxxxxxxx xxxxxxxx
xxxxxxxx xxxxxxxx
Characters Description / Meaning Length
5200 FRU 1 - Ref Code = 5200 4 Characters
245E FRU 1 - Type = 245E 4 Characters
8100 FRU 2 - Ref Code = 8100 4 Characters
3197 FRU 2 - Type = 3197 4 Characters
9300 FRU 3 - Ref Code = 9300 4 Characters
25AA FRU 3 - Type = 25AA 4 Characters
Below is the information as shown in a MSD SCREEN:
1 - B4xx____RC01TP01RC02RC03RC04RC05
2 - DATA0012
3 - DATA0013
4- TP02TP03
5- TP04TP05
.
.
.
9 - DATA0019
The FRU information for FRU 1 would be FI1A and FI1B or for FRU 2 it would be
FI2A and FI2B, and so forth.
The first part of the FRU information is the unit reference code. Find the unit
reference codes in the table below to determine the Priority and Location of the
failing items. See “Locations and Addresses” on page 705 for the physical mapping
of the information in the Location column.
Note: The priorities are:
v Mandatory: You should replace all mandatory failing items before the
next IPL.
v High:This part has a high probability of resolving the problem. Replace
high priority failing items in order, one at a time with an IPL in between.
v Low: This part has a low probability of resolving the problem. Replace
low priority failing items after replacement of mandatory and high
priority items.
The second part of the FRU information is the type number. This will be used in
combination with the Failing Item information to determine the Part Number from
the ″Type, Model, and Part Number″ list.
v If the failing item is given as a FI code, go to “Failing Items” on page 479.
Determine the part number that is associated with the failing FI code.
v If the failing item is given as a Symbolic FRU, go to “Symbolic FRUs” on
page 495 to determine the part number.
B467
230
iSeries Model 830, 840, SB2, and SB3 Problem Analysis, Repair and Parts V5R1
