6. Perform the following:
a. Power off the system (see “Powering On and Powering Off the System and
Logical Partitions” on page 922).
b. Restore all I/O cards to their original position.
c. Select the IPL type and mode that are used by the customer (see iSeries
Service Functions).
d. Power on the system.
7. Does the IPL complete successfully?
No Yes
↓ This ends the procedure.
8. Ask your next level of support for assistance.
This ends the procedure.
Storage Device I/O Card FRU Locations
Use Table 14 to find FRU locations. If only a type number is listed, go to the “Type,
Model, and Part Number list” on page 885 to determine the part number. If the
failing item is an FI code, see “Failing Items” on page 479.
Note: See “Locations and Addresses” on page 705 to help find FRUs that are not in
this table.
Table 14. Storage Device I/O card FRU Locations
FRU Description Location Procedure
v Diskette adapter (type 6146
or type 6147)
Use the location information in the Service Action Log if it is available. If the
location is not available, find the address. See “SRC Address Formats” on page 936.
Use the address to find the location. See “Locations and Addresses” on page 705.
Terminating plug See “DEVTERM” on page 525 for more information.
Also see “Locations and Addresses” on page 705.
Service Processor Problem Isolation Procedures
Overview
This section contains the procedures necessary to isolate a failure that has been
detected by the service processor. This section covers the following items:
v Bus unit
v Magnetic storage I/O processor card
v Service processor card or a card in the wrong slot
v Match problems between the hardware and software
v Information needed to perform a removable media or a disk IPL from the
control panel
Note: These procedures should be performed by selecting Manual mode on the
control panel.
Read all safety procedures before servicing the system. Observe all safety
procedures when performing a procedure. Unless instructed otherwise,
always power off the system or expansion tower where the FRU is located,
(see “Powering On and Powering Off the System and Logical Partitions” on
page 922) before removing, exchanging, or installing a field-replaceable unit
(FRU).
SDIOP PIPs
Chapter 3. Problem Isolation Procedures (PIPs), Failing Items, and Symbolic FRU Isolation 437
