Table 34. (continued)
System Model,
Towe r,
Expansion
Unit, or
Machine Type
Name of FRU
to Exchange
FRU Position Link to
Location
Diagram
Link to Failing
Component Service
Information. (CCIN,
PN, Removal and
Installation Procedure)
Models 830
and SB2 base
I/O tower (FC
9074)
HSL I/O
Bridge Card
C08 “Locations —
Models 830,
SB2 System
Unit with FC
9074 Base I/O
Tower” on
page 709.
Table 41 on page 710.
Models 840
and SB3 base
I/O tower (FC
9079)
HSL I/O
Bridge Card
C08 Figure 36 on
page 724.
Table 43 on page 725.
External
xSeries Server
Integrated
xSeries
Adapter Card
Follow the
HSL cables.
Go to
“Locations —
Integrated
xSeries
Adapter Card
(IXA),
Formerly the
Adapter for
Netfinity
Server” on
page 748.
Go to Table 47 on
page 749.
This ends the procedure.
SIRGCBL
SIRGCBL: high-speed link (HSL) loop cable.
This failing component is an HSL loop cable, the HSL loop connections (external or
embedded) or an HSL interposer card in a HSL loop.
Note: When exchanging HSL optical cables use the optical cleaning kit and
procedures. See symbolic FRU “OPT_CLN” on page 561 for additional
information on the optical cleaning kit and procedures.
1. Were you sent to this Symbolic FRU as a result of a B4xx SRC?
No Yes
↓ Use the location given in the SRC table to determine the failing HSL
port. In the table below is a list of system models, towers, expansion
units and machine types with the HSL connections in each.
2. The loop number may be given in the FRU description and location
information of the SAL, in decimal format. The loop number is in the left four
digits of word 7 of the SRC in hexadecimal format. In the table below is a list
of system models, towers, expansion units and machine types with the HSL
connections in each.
Symbolic FRUs
588
iSeries Model 830, 840, SB2, and SB3 Problem Analysis, Repair and Parts V5R1
