determined by including the digits ″1000″ to the beginning of the
12-digit IEEE Address found on the tailstock label of the Fibre Channel
IOA. Use the ESS Web Interface User’s Guide (SC26–7346) to update the
World-Wide Port-Name in the host configuration on the IBM 2105 ESS.
The ESS Web Interface User’s Guide can also be found at the following
URL: http://www.storage.ibm.com/hardsoft/products/ess/refinfo
This ends the procedure.
Models 830/SB2 with FC 9074 – Covers
Attention: If removing the cover while powered on, errors may occur due to
Electromagnetic Interference.
Note: The front and rear covers will swing open to a little more than 90 degrees.
This makes it possible to replace all FRUs, without having to remove the
covers.
To open the or remove the bottom front cover, refer to Figure 19 on page 664 and
perform the following steps:
1. Unlock the cover (front only)
2. Release the cover latching mechanism by pushing in on the blue button ″A″
that is located midway along the right edge of the cover.
3. Grasp the top, right corner of the cover and pull it towards you to open it.
4. After opening the cover, press down on the lever ″B″ that is located inside
along the top, left side of the cover.
5. Tilt the top of the cover away from the tower and lift the cover off.
This ends the procedure.
6. To open or remove the rear cover, refer to “Assembly 1: Models 830 and SB2
with FC 9074 – Cover Assembly” on page 804 and perform the following
steps:
a. Grasp the top, right corner of the cover and pull it towards you to open it.
b. Tilt the top of the cover away from the tower and lift the cover off.
This ends the procedure.
7. To remove the top front cover “Assembly 1: Models 830 and SB2 with FC
9074 – Cover Assembly” on page 804 and perform the following steps:
a. Grasp both the sides of the top cover.
b. Lift the top of the cover up and away from the tower.
This ends the procedure.
Remove and Replace Procedures
Chapter 4. Removal and Installation Procedures 663
