Reference
Code
Priority Description Failing Item Location
F30E Low Optical link on Bus Expansion Adapter card
failed
FI00017 S10A
F30F Low Optical link on Bus Expansion Adapter card
failed
FI00017 S10A, B, C
F3FF Low Bus expansion card FI00015 S07, S09, S10
Model 840 and SB3 System Processor Failing Items
Failing Item Description Document Description
AJDG301 Licensed Internal Code error Service Functions; APAR or LICTR
AJDGP01 Service processor Licensed Internal Code Service Functions; APAR or LICTR
ANYMEM System Card(s) or BackPlane Problem Analysis; Symbolic FRU Isolation
ANYPROC System Card(s) or BackPlane Problem Analysis; Symbolic FRU Isolation
CCIN System Card(s) or BackPlane Problem Analysis; Symbolic FRU Isolation
CTLPNCD System Sub-Card(s) Problem Analysis; Symbolic FRU Isolation
CTLPNL Control panel Problem Analysis; Symbolic FRU Isolation
MUMIOCD Bus expansion card Problem Analysis; Symbolic FRU Isolation
NEXTLVL Call your next level of support for assistance Problem Analysis; Symbolic FRU Isolation
NOMSUSE Main storage failure Problem Analysis; Symbolic FRU Isolation
RIOPORT System bus error Problem Analysis; Symbolic FRU Isolation
(B4FF) System Processor Reference Codes
A major system problem has occurred.
The reference code is the first eight characters of the display data for panel
function 11.
1. Is the reference code B4FF0003?
No Yes
↓ The System cannot find any processors. Any processor may be the
failing item. Refer to Symbolic FRU “ANYPROC” on page 503, for the
procedure to determine processor location and part information.
If this does not fix the problem, contact your next level of support.
This ends the procedure.
2. Is the reference code B4FF00B0 or B4FF00B1?
Yes No
↓ Go to step 6 on page 239 of this procedure.
3. If the reference code is B4FF00B1, then the HSL I/O bridge card may be the
failing item. If the reference code is B4FF00B0, then the HSL I/O bridge Card
may be the failing item, or the failure may be caused by the Licensed Internal
code. For either reference code, perform the following:
B467
238
iSeries Model 830, 840, SB2, and SB3 Problem Analysis, Repair and Parts V5R1
