Table 33. (continued)
System Model,
Towe r,
Expansion
Unit, or
Machine Type
Name of FRU
to Exchange
FRU Position Link to
Location
Diagram
Link to Failing
Component Service
Information. (CCIN,
PN, Removal and
Installation Procedure)
FC 5033, FC
5034, or FC
5035 SPD
Migrated
Tower
Go to symbolic FRU CVTCARD in the Migrated Expansion Tower Problem
Analysis, Repair and Parts.
This ends the procedure.
SI_PHB
SI_PHB: high-speed link PCI host bridge.
The HSL I/O bridge hardware in a base I/O tower or I/O expansion tower is
failing. Follow the procedure to identify the failing component to exchange.
1. If you are working from the Service Action Log and a card position is listed
with this FRU, then that is where the error is located, continue with the next
step in this procedure. Otherwise, record the bus number value, BBBB, in word
7 of the SRC, see “Breaking Down The SRC” on page 280 for help in
determining the bus number. Search for the bus number in HSM or the System
Configuration Listing to determine which frame or I/O tower contains the
failing item. Record the frame or tower type.
2. Use the system model, tower, expansion unit or machine type and the table
below to determine the service information for the failing component.
Table 34.
System Model,
Towe r,
Expansion
Unit, or
Machine Type
Name of FRU
to Exchange
FRU Position Link to
Location
Diagram
Link to Failing
Component Service
Information. (CCIN,
PN, Removal and
Installation Procedure)
FC 5074 HSL I/O
Bridge Card
C08 “Locations —
FC 5074 I/O
Tower” on
page 736.
Table 44 on page 737.
FC 5075 Tower Card CB1 “Locations —
FC 5075 I/O
Tower” on
page 740.
Table 45 on page 741.
FC 5078/0578 HSL I/O
Bridge Card
C08 “Locations —
FC 5078, 0578
PCI Expansion
Unit” on
page 743.
Table 46 on page 744.
FC 5079 (1.8m
expansion
tower)
HSL I/O
Bridge Card
C08 “Locations —
FC 5079 I/O
Tower” on
page 747.
Table 44 on page 737.
Symbolic FRUs
Chapter 3. Problem Isolation Procedures (PIPs), Failing Items, and Symbolic FRU Isolation 587
